Description
Description
- Cover included.
- Accepts 5/16″ (M8) ring terminals.
- For use on systems up to 32 Volts DC.
- Swing out design allows replacement of the fuse without removing fasteners.
- Stainless steel studs provide resistance to corrosion and high torquing for excellent electrical contact.
- UL 94-V0 base resists high heat.
- Insert molded studs ensure secure fuse mounting.
- Insulating cover satisfies ABYC/USCG requirements.
- Cover breakouts allow wire access in any direction.
- Fuse sold separately.
Features
Specification
| Stud Size | : | 5/16 |
| Maximum Voltage | : | 32VDC |
| Maximum Cable Size | : | 4/0 AWG |
| Maximum Torque | : | 107 in-lb |
| Stud Torque | : | 107 in-lb |
| Terminal Stud Size | : | 5/16- 18 (M8) |
| Fuse Mounting Blocks | : | Tin-Plated Copper |
| Weight | : | 0.48Kg |
| Warranty | : | 1 Year |
Compatibility
Please make sure your current battery has the matching required specification to ensure a like for like replacement.
Compatibility Check
Before sending out your ordered part(s), we perform a compatibility check to guarantee that they will fit your vehicle. This verification can be done by using your registration number (UK) or the last 7 digits of your VIN. Simply enter your car information before proceeding to checkout.
Part Number
BLUE SEA-5503B-BSS
More Information
Manufactured by
BLUE SEA
Reviews
There are no reviews yet.
